1. Machine height can be varied up to – 3000 mm
2. Space has to be provided as per Crucible dimension/height
3. Machine of ground level – Rotor 1000 mm
4. Machine center arm length – 1250 mm

Electric supply:- 415-volt 3 phase 20 AMPS load Suitable length of electric cable as per site plan to be provided

2.5 square meter AC dive – ABB make for rotor RPM 0 – 900 RPM

Power contactors/MCB/MPCB / emergency on/off – L&T/Siemens/ABB

1.     Up and down movement: – with control by limit switches, motor 1 HP – Bharat Bijlee/Siemens/ABB

2.     Rotor Motor – 2 HP 415 volt (Bharat Bijlee/Siemens Moto F class, AC drive – ABB

3.     Swing Movement: – 188 (90 deg left, 90 deg right), manual locking for safety at 0 deg 45 deg 90 deg each side

• Supply of machine
• Installation of machine
• Commissioning of machine
• Dry cycle operations 5 no’s
• Providing foundation drawing
• Manual of machine

• Power supply
• Civil work & foundation
• Tools & shackles

1. Electrical supplies as per original part suppliers of standard make
2. 1 year against the mechanical movement & gas control
3. In case of normal wear tear or centre not used properly it would be responsibility of client

All Cast would be able to attend most of the problems, we offer the center with Force Majeure Clause
